How Does an Electric Motor Work?
If you’re an electrical engineer, you know how an electric motor works. If you aren’t, it can be extremely confusing, therefore, here’s the simplified explanation (or the “how an electric motor works for dummies” version) of how a four pole, three phase AC induction motor works in a car.
It starts with the battery in the car that is connected to the motor. Electrical energy is supplied to the stator via the car’s battery. The coils within the stator (made from the conducting wire) are arranged on opposite sides of the stator core and act as magnets in a way. Therefore, when the electrical energy from the car battery is supplied to the motor, the coils create rotating magnetic fields that pull the conducting rods on the outside of the rotor along behind it. The spinning rotor is what creates the mechanical energy need to turn the gears of the car, which, in turn, rotate the tires.
Now, in a typical car that isn’t electric, there is both an engine and an alternator. The battery powers the engine, which powers the gears and wheels. The rotation of the wheels is what then powers the alternator in the car and the alternator recharges the battery. This is why you are told to drive your car around for a period of time after being jumped - the battery needs to be recharged in order to function appropriately.
In an electric car, there is no alternator. So, how does the battery recharge then? While there is no separate alternator, the motor in an electric car acts as both the motor and an alternator. That’s one of the reasons why electric cars are so unique. As referenced above, the battery starts the motor, which supplies energy to the gears, which rotates the tires. This process happens when your foot is on the accelerator - the rotor gets pulled along by the rotating magnetic field, requiring more torque. But what happens when you let off of the accelerator?
When your foot comes off the accelerator, the rotating magnetic field stops and the rotor starts spinning faster (as opposed to being pulled along by the magnetic field). When the rotor spins faster than the rotating magnetic field in the stator, this action recharges the battery, acting as an alternator.
To further simplify this process - imagine pedaling a bike up a hill. To get to the top of the hill, you need to pedal harder and may even have to stand up and expend more energy to rotate the tires and reach the peak of the hill. This is similar to pressing down on the gas. The rotating magnetic field pulling the rotor behind it creates the resistance (or torque) needed to move the tires and car. Once at the peak of the hill, you can take it easy and recharge while the wheels move even faster to take you down the hill. In the car, this happens when you let your foot off the gas and the rotor moves faster and feeds electrical energy back into the power line to recharge the battery.
What is Alternating Current (AC) vs Direct Current (DC)?
The conceptual differences behind these two types of currents is seemingly fairly obvious. While one current is consistent, the other is more intermittent. However, things are a bit more complicated than just that simple explanation, so let’s break these two terms out in a bit more detail.
Direct Current (DC)
The term direct current refers to electricity that moves in a singular and consistent direction at all times. Furthermore, a direct current’s voltage maintains a regular polarity, that is, one that does not change.
Think of how batteries have clearly defined positive and negative sides to them. They use direct currents to send the same voltage out on a consistent basis. In addition to batteries, fuel cells and solar cells also produce direct currents, while simple acts like rubbing certain materials together can produce DC as well.
In keeping with our battery concept, when considering the positive and negative sides of the battery, it is important to note that the direct current always flows the same direction between the positive and negative side. This ensures that both sides of the battery are always positive and negative.
Alternating Current (AC)
The term alternating current defines a type of electricity characterized by voltage (think water pressure in a hose) and current (think rate of water flow through the hose) which vary with respect to time. As the voltage and current of an AC signal change, they most often follow the pattern of a sine wave (in the image above, the sine wave is shown in the right voltage graph). Due to the waveform being a sine wave, the voltage and current alternate between a positive and negative polarity when viewed over time. The sine wave shape of AC signals is due to the way in which the electricity is generated.
Another term you may hear when discussing AC electricity is frequency. The frequency of the signal is the number of complete wave cycles completed during one second of time. Frequency is measured in Hertz (Hz) and in the United States, the standard power-line frequency is 60 Hz. This means that the AC signal oscillates at a rate of 60 complete back-forth cycles every second.
So why is this important?
AC electricity is the best way to transfer useable energy from a generation source (i.e., a dam or windmill) over great distances. This is due to the alternating nature of the AC signal which allows the voltage to be easily stepped up or stepped down to different values. This is why your home's outlets will say 120 volts AC (safer for human consumption) but the voltage of a distribution transformer which supply power to a neighborhood (those cylindrical grey boxes you see on the power line poles), might have voltage as high as 66 kVA (66,000 volts AC).
AC power allows us to construct generators, motors, and distribution systems from electricity that are far more efficient than direct current, which is why AC is the most popular energy current for powering applications.
